- Place of Origin: China
- Brand Name: KEC
- Model Number: QC12Y
tandard controller:simple numercial controller
Optional Digital System:China ESTUN E10S
Performance profile:
1.The machine is metal plate welded structure, with hydraulic transmission and accumulator return,typical of an easy operation, reliable performance, and nice appearance, fitted with digital controller.
2.Indication by indicator is provided for adjustment of blades clearance, for a handy and prompt adjustment.
3.Alignment device with lighting and conrtrol device for shearing stroke are set.
4.Worktable with balls for material feeding convenient, to minimize fish tail with sheet bar and to reduce frictional resistance.
- Place of Origin: China
- Brand Name: KEC
- Model Number: QC12Y
TYPE | CUT THINCKNESS | CUT WIDE | CUT ANGLE | STROKE TIMES | BACK GAUGE RANGE | POWER(kw) | OUTLINE DIMENSION(L×W×H)(mm) |
4×2500 | 4 | 2500 | 1°30 | ≥18 | 20-600 | 4 | 3040×1610×1650 |
4×3200 | 4 | 3200 | 1°30 | ≥14 | 20-600 | 5.5 | 3840×1610×1650 |
4×4000 | 4 | 4000 | 1°30 | ≥10 | 20-600 | 5.5 | 4640×1705×1700 |
4×5000 | 4 | 5000 | 1°30 | ≥10 | 20-600 | 7.5 | 5786×2200×2160 |
6×2500 | 6 | 2500 | 1°30 | ≥18 | 20-600 | 7.5 | 3140×1610×1650 |
6×3200 | 6 | 3200 | 1°30 | ≥14 | 20-600 | 7.5 | 3840×1610×1650 |
6×4000 | 6 | 4000 | 1°30 | ≥10 | 20-600 | 7.5 | 4640×1705×1700 |
6×5000 | 6 | 5000 | 1°30 | ≥10 | 20-750 | 11 | 5786×2200×2160 |
6×6000 | 6 | 6000 | 1°30 | ≥7 | 20-800 | 15 | 6900×2570×2280 |
8×2500 | 8 | 2500 | 1°30 | ≥14 | 20-600 | 11 | 3040×1610×1650 |
8×3200 | 8 | 3200 | 1°30 | ≥10 | 20-600 | 11 | 3840×1610×1650 |
8×4000 | 8 | 4000 | 1°30 | ≥8 | 20-600 | 11 | 4860×1705×1700 |
8×5000 | 8 | 5000 | 1°30 | ≥7 | 20-750 | 15 | 5786×2252×2310 |
8×6000 | 8 | 6000 | 1°30 | ≥5 | 20-750 | 18.5 | 6900×2570×2280 |
10×2500 | 10 | 2500 | 1°30 | ≥11 | 20-800 | 15 | 3350×2050×1950 |
10×3200 | 10 | 3200 | 1°30 | ≥10 | 20-600 | 15 | 4050×2050×1950 |
10×4000 | 10 | 4000 | 1°30 | ≥12 | 20-600 | 18.5 | 4800×2200×2100 |
12×2500 | 12 | 2500 | 1°30 | ≥11 | 20-600 | 18.5 | 3350×2050×1950 |
12×3200 | 12 | 3200 | 1°30 | ≥10 | 20-800 | 18.5 | 4020×2050×2230 |
12×4000 | 12 | 4000 | 1°30 | ≥8 | 20-800 | 18.5 | 4820×2400×2730 |
16×2500 | 16 | 2500 | 2° | ≥8 | 20-800 | 18.5 | 3520×2060×2350 |
16×3200 | 16 | 3200 | 2° | ≥7 | 20-800 | 22 | 4062×2300×2320 |
16×4000 | 16 | 4000 | 2° | ≥5 | 20-800 | 22 | 4850×2350×2300 |
20×2500 | 20 | 2500 | 2°30 | ≥6 | 20-800 | 37 | 3400×2088×2570 |
20×3200 | 20 | 3200 | 2°30 | ≥5 | 30-800 | 37 | 4150×2350×2710 |
20×4000 | 20 | 4000 | 2°30 | ≥5 | 30-1000 | 37 | 4920×2400×2730 |
20×5000 | 20 | 5000 | 2°30 | ≥4 | 20-800 | 37 | 5900×3000×3300 |
25×2500 | 25 | 2500 | 3° | ≥5 | 40-800 | 45 | 3500×2400×2500 |
25×3200 | 25 | 3200 | 3° | ≥4 | 30-800 | 45 | 4200×2400×2500 |
25×4000 | 25 | 4000 | 3° | ≥4 | 30-800 | 45 | 4950×2500×2600 |
30×2500 | 30 | 2500 | 3° | ≥4 | 30-800 | 45 | 3300×2900×3000 |
30×3200 | 30 | 3200 | 3°30 | ≥4 | 30-800 | 45 | 4200×2500×2600 |
40×2500 | 40 | 2500 | 4° | ≥3 | 30-800 | 75 | 3200×3300×3200 |
40×3200 | 40 | 3200 | 4° | ≥3 | 30-800 | 90 | 4300×3300×3000 |
